The Complete Creo to Rhino 3DM Conversion Guide
Table of Contents
- General Information
- Converting and Optimizing Creo Files to Rhino 3DM
- What are Creo and Rhino 3DM files commonly used for?
- Comparison of Features Supported by Creo and Rhino 3DM
- Limitations of Creo Files to Rhino 3DM Conversion Workflow
- What's the best way to get Creo files into my 3D applications, and are there alternatives to using Rhino 3DM?
General Information
This guide is part of the RapidPipeline 3D Formats Knowledge Database. It shows how to convert Creo to Rhino 3DM, if you'd like to know more about the formats, please check out the following links:
Converting and Optimizing Creo Files to Rhino 3DM
RapidPipeline can import Creo files, but currently doesn't support exporting to Rhino 3DM format yet.
If you specifically need Rhino 3DM export functionality for your workflow, please feel free to get in touch with us - we'd be happy to discuss your requirements and potential timeline for adding this export capability.
If you need, you can import Rhino 3DM files and convert them to any of these 8 formats: FBX, glTF, OBJ, PLY, STL, USD, USDZ, and VRM.
In the meantime, you can explore other options on the 3D Formats Knowledge Database, which might serve as suitable alternatives for your workflow depending on your target applications and use cases.
Comparison of Features Supported by Creo and Rhino 3DM
| Feature | Supported by Creo | Supported by Rhino 3DM |
|---|---|---|
| Morph Targets | No | No |
| Rigid Animations | Yes | No |
| Skinned Animations | No | No |
| Animations | Yes | No |
| Free-Form Surfaces | Yes | Yes |
| Geometry Compression | No | No |
| Quad Meshes | Yes | Yes |
| Basic 3D Geometry | Yes | Yes |
| PBR Materials | Partial0 | Yes |
| Transparent Materials | Yes | Yes |
| Vertex Colors | Partial1 | Yes |
| Materials | Yes | Yes |
| Scene Composition | Yes | Yes |
| Hierarchical Scene Graph | Yes | Yes |
| Scene Nodes | Yes | Yes |
| Standardized Format | Partial2 | Partial3 |
| Embedded Textures | Partial4 | Partial5 |
| Multiple UV Channels | Partial6 | Yes |
| Normal Mapping | No | Yes |
| Procedural Textures | No | Partial7 |
| Texture Compression | No | No |
| Texture Transforms | Partial8 | Yes |
| Texturing | Partial9 | Yes |
Limitations of Creo Files to Rhino 3DM Conversion Workflow
The following limitations should be taken into account when converting Creo files to Rhino 3DM format:
| Creo Feature (not supported by Rhino 3DM) | Limitation Details |
|---|---|
| Animations | Animations Support: Creo: Full support | Rhino 3DM: No support   Impact: Animations are an important part of many interactive 3D assets, for example in real-time rendering (including games, XR training, assembly instructions, product demos, and other use cases). There are various kinds of animations that can be used on 3D models. In this example model, a rigid animation is used to make the gears spin. Without support for this feature, in this example, the gears won't move. |
| Rigid Animations | Rigid Animations Support: Creo: Full support | Rhino 3DM: No support   Impact: Rigid Animations are typically used to animate mechanical parts. In this example, the door of this 3D model of a microwave can be interactively opened or closed, using a rigid animation that gradually changes the 3D transformation of the door. Without support for this feature, in this example, the door will just stay in place and won't move. |
What's the best way to get Creo files into my 3D applications, and are there alternatives to using Rhino 3DM?
Doing 3D conversion right, especially at scale, can be tricky, as 3D data is in general a rather complex (yet very powerful!) medium. This also applies to Creo and Rhino 3DM files - the conversion guide above provides a rough first idea about that. Once you know what you would like to do, tools like RapidPipeline can help you perform the necessary steps, and to even automate the process for thousands or even millions of files.
Especially when introducing pipelines and workflows at scale in an enterprise context, it is usually good to rely on dedicated tools and expertise, making sure you do not introduce any steps into your 3D workflow that are detrimental to the final output's quality, or that take your team too much time (and money).
If you're interested to hire dedicated expertise from the best in the field to help your company reach your goals fast and reliably, please do not hestitate to contact DGG. Being the creators of RapidPipeline, and ambassadors for open 3D standards for more than a decade, we have been building some of the world's most advanced 3D pipelines, having processed many millions of 3D assets.
Therefore, our expertise will help you to reach your goals faster, at scale, and with the least possible friction, since we are focused on maximum interoperability.
To get started with 3D data conversion and optimization today, sign up for a free account!
If you have any questions, feel free to chat with our human team.
