The Complete OBJ to 3MF Conversion Guide
Table of Contents
- General Information
- Converting and Optimizing OBJ Files to 3MF
- What are OBJ and 3MF files commonly used for?
- Comparison of Features Supported by OBJ and 3MF
- Limitations of OBJ Files to 3MF Conversion Workflow
- What's the best way to get OBJ files into my 3D applications, and are there alternatives to using 3MF?
General Information
This guide is part of the RapidPipeline 3D Formats Knowledge Database. It shows how to convert OBJ to 3MF, if you'd like to know more about the formats, please check out the following links:
Converting and Optimizing OBJ Files to 3MF
RapidPipeline can import OBJ files, but currently doesn't support exporting to 3MF format yet.
If you specifically need 3MF export functionality for your workflow, please feel free to get in touch with us - we'd be happy to discuss your requirements and potential timeline for adding this export capability.
If you need, you can import 3MF files and convert them to any of these 8 formats: FBX, glTF, OBJ, PLY, STL, USD, USDZ, and VRM.
In the meantime, you can explore other options on the 3D Formats Knowledge Database, which might serve as suitable alternatives for your workflow depending on your target applications and use cases.
Comparison of Features Supported by OBJ and 3MF
| Feature | Supported by OBJ | Supported by 3MF |
|---|---|---|
| Morph Targets | No | No |
| Rigid Animations | No | No |
| Skinned Animations | No | No |
| Animations | No | No |
| Free-Form Surfaces | No | No |
| Geometry Compression | No | Partial0 |
| Quad Meshes | Yes | No |
| Basic 3D Geometry | Yes | Yes |
| PBR Materials | Partial | Partial1 |
| Transparent Materials | Yes | Partial2 |
| Vertex Colors | No | Yes |
| Materials | Yes | Yes |
| Scene Composition | No | Yes |
| Hierarchical Scene Graph | No | Yes |
| Scene Nodes | Yes | Yes |
| Standardized Format | Partial3 | Yes |
| Embedded Textures | No | Yes |
| Multiple UV Channels | No | Partial4 |
| Normal Mapping | Partial | No |
| Procedural Textures | No | No |
| Texture Compression | No | Partial5 |
| Texture Transforms | No | Partial6 |
| Texturing | Yes | Yes |
Limitations of OBJ Files to 3MF Conversion Workflow
The following limitations should be taken into account when converting OBJ files to 3MF format:
| OBJ Feature (not supported by 3MF) | Limitation Details |
|---|---|
| Quad Meshes | Quad Meshes Support: OBJ: Full support | 3MF: No support   Impact: Quad meshes are a common way to hand-model and edit 3D models. 3D artists get intuitive control and such meshes are also easy to refine, as well as well-suited for creation of skinned animations. However, real-time rendering pipelines and hardware are usually all based on triangles, so if a 3D model should not be edited any more, it is safe to convert quads to triangles (and engines will do this automatically before sending data to the rendering hardware). In this example, a part of a mesh is modeled with quads. Without support for this feature, quads will have to be triangulated, producing a pure triangle mesh. |
| Normal Mapping | Normal Mapping Support: OBJ: Partial support | 3MF: No support   Impact: Normal maps are used to model shading differences that are arising from small geometric details on a surface, such as fabric structures, visible gaps between bricks forming a wall, or rough rock surfaces. In this example, a normal map is used to model a fabric structure. Without support for this feature, the rendered fabric will look smoother than it actually is in the real world, as the fabric structure won't be visible. |
| Transparent Materials | Transparent Materials Support: OBJ: Full support | 3MF: Partial support   3MF Notes: Alpha channel support for transparency Impact: Transparency is commonly used for see-through objects, containing (usually partially) transparent surfaces. In this example, a transparent material is used to model the glass window of the microwave, so that one can see inside. Without support for this feature, the inside of the microwave cannot be seen, as the window will be rendered as an opaque surface. |
What's the best way to get OBJ files into my 3D applications, and are there alternatives to using 3MF?
Doing 3D conversion right, especially at scale, can be tricky, as 3D data is in general a rather complex (yet very powerful!) medium. This also applies to OBJ and 3MF files - the conversion guide above provides a rough first idea about that. Once you know what you would like to do, tools like RapidPipeline can help you perform the necessary steps, and to even automate the process for thousands or even millions of files.
Especially when introducing pipelines and workflows at scale in an enterprise context, it is usually good to rely on dedicated tools and expertise, making sure you do not introduce any steps into your 3D workflow that are detrimental to the final output's quality, or that take your team too much time (and money).
If you're interested to hire dedicated expertise from the best in the field to help your company reach your goals fast and reliably, please do not hestitate to contact DGG. Being the creators of RapidPipeline, and ambassadors for open 3D standards for more than a decade, we have been building some of the world's most advanced 3D pipelines, having processed many millions of 3D assets.
Therefore, our expertise will help you to reach your goals faster, at scale, and with the least possible friction, since we are focused on maximum interoperability.
To get started with 3D data conversion and optimization today, sign up for a free account!
If you have any questions, feel free to chat with our human team.
