The Complete STL to SolidWorks Conversion Guide
Table of Contents
- General Information
- Converting and Optimizing STL Files to SolidWorks
- What are STL and SolidWorks files commonly used for?
- Comparison of Features Supported by STL and SolidWorks
- Limitations of STL Files to SolidWorks Conversion Workflow
- What's the best way to get STL files into my 3D applications, and are there alternatives to using SolidWorks?
General Information
This guide is part of the RapidPipeline 3D Formats Knowledge Database. It shows how to convert STL to SolidWorks, if you'd like to know more about the formats, please check out the following links:
Converting and Optimizing STL Files to SolidWorks
There are various ways to convert between STL and SolidWorks. With RapidPipeline, you can easily convert and and optimize STL files, at scale. It supports SolidWorks, as well as many other file formats (examples: 3dsMax, CATIA, Creo, FBX, glTF, OBJ, PLY, STEP, USD, USDZ, VRM), at high quality.
Below you can find a video explaining how to convert your files:
What are STL and SolidWorks files commonly used for?
The STL file is a format mostly used for 3D printing.
The SolidWorks file is a format mostly used for Professional 3D CAD software for mechanical design and product development.
Comparison of Features Supported by STL and SolidWorks
| Feature | Supported by STL | Supported by SolidWorks |
|---|---|---|
| Morph Targets | No | No |
| Rigid Animations | No | Yes |
| Skinned Animations | No | No |
| Animations | No | Yes |
| Free-Form Surfaces | No | Yes |
| Geometry Compression | No | No |
| Quad Meshes | No | Yes |
| Basic 3D Geometry | Yes | Yes |
| PBR Materials | No | Yes |
| Transparent Materials | No | Yes |
| Vertex Colors | No | Partial0 |
| Materials | No | Yes |
| Scene Composition | No | Yes |
| Hierarchical Scene Graph | No | Yes |
| Scene Nodes | No | Yes |
| Standardized Format | Yes | Partial1 |
| Embedded Textures | No | Partial2 |
| Multiple UV Channels | No | Partial3 |
| Normal Mapping | No | Partial4 |
| Procedural Textures | No | Partial5 |
| Texture Compression | No | No |
| Texture Transforms | No | Yes |
| Texturing | No | Yes |
Limitations of STL Files to SolidWorks Conversion Workflow
The following limitations should be taken into account when converting STL files to SolidWorks format:
| STL Feature (not supported by SolidWorks) | Limitation Details |
|---|---|
| Standardized Format |   Standardized Format: supported in STL, but not in SolidWorks. Standardization plays a huge role in 3D model formats. With a format being standardized, every application will have a clear way of how to load or store data using this format. This makes it easier to re-use the 3D model across different applications, but also to make sure it will still be accessible and usable after a couple of years. |
What's the best way to get STL files into my 3D applications, and are there alternatives to using SolidWorks?
Doing 3D conversion right, especially at scale, can be tricky, as 3D data is in general a rather complex (yet very powerful!) medium. This also applies to STL and SolidWorks files - the conversion guide above provides a rough first idea about that. Once you know what you would like to do, tools like RapidPipeline can help you perform the necessary steps, and to even automate the process for thousands or even millions of files.
Especially when introducing pipelines and workflows at scale in an enterprise context, it is usually good to rely on dedicated tools and expertise, making sure you do not introduce any steps into your 3D workflow that are detrimental to the final output's quality, or that take your team too much time (and money).
If you're interested to hire dedicated expertise from the best in the field to help your company reach your goals fast and reliably, please do not hestitate to contact DGG. Being the creators of RapidPipeline, and ambassadors for open 3D standards for more than a decade, we have been building some of the world's most advanced 3D pipelines, having processed many millions of 3D assets.
Therefore, our expertise will help you to reach your goals faster, at scale, and with the least possible friction, since we are focused on maximum interoperability.
To get started with 3D data conversion and optimization today, sign up for a free account!
If you have any questions, feel free to chat with our human team.
