The Complete JT to PRC/U3D Conversion Guide
General Information
This guide is part of the RapidPipeline 3D Formats Knowledge Database.It shows how to convert JT to PRC/U3D, if you'd like to know more about the formats, please check out the following links:
Converting and Optimizing JT Files to PRC/U3D
RapidPipeline can import JT files, but currently doesn't support exporting to PRC/U3D format yet.
If you specifically need PRC/U3D export functionality for your workflow, please feel free to get in touch with us - we'd be happy to discuss your requirements and potential timeline for adding this export capability.
If you need, you can import PRC/U3D files and convert them to any of these 8 formats: FBX, glTF, OBJ, PLY, STL, USD, USDZ, and VRM.
In the meantime, you can explore other options on the 3D Formats Knowledge Database, which might serve as suitable alternatives for your workflow depending on your target applications and use cases.
What are JT and PRC/U3D files commonly used for?
The JT file is a format mostly used for lightweight 3D visualization and collaboration.
The PRC/U3D file is a format mostly used for 3D data embedding in documents and technical publishing.
Best-in-Class 3D Processing in Your Favorite Tools.
100% Local Processing via Desktop Software.
Comparison of Features Supported by JT and PRC/U3D
| Feature | Supported by JT | Supported by PRC/U3D |
|---|---|---|
| Morph Targets | No | Partial0 |
| Rigid Animations | Partial1 | Yes |
| Skinned Animations | No | Partial2 |
| Animations | Partial3 | Yes |
| Free-Form Surfaces | Yes | Yes |
| Geometry Compression | Yes | Yes |
| Quad Meshes | Yes | Yes |
| Basic 3D Geometry | Yes | Yes |
| PBR Materials | No | No |
| Transparent Materials | Yes | Yes |
| Vertex Colors | Yes | Yes |
| Materials | Yes | Yes |
| Scene Composition | Yes | Yes |
| Hierarchical Scene Graph | Yes | Yes |
| Scene Nodes | Yes | Yes |
| Standardized Format | Yes | Yes |
| Embedded Textures | Yes4 | Yes |
| Multiple UV Channels | Partial5 | Yes |
| Normal Mapping | Yes6 | Partial7 |
| Procedural Textures | Partial8 | No |
| Texture Compression | Partial9 | Partial10 |
| Texture Transforms | Yes11 | Yes |
| Texturing | Yes | Yes |
Best-in-Class 3D Processing in Your Favorite Tools.
100% Local Processing via Desktop Software.
Limitations of JT Files to PRC/U3D Conversion Workflow
The following limitations should be taken into account when converting JT files to PRC/U3D format:
| JT Feature (not supported by PRC/U3D) | Limitation Details |
|---|---|
| Procedural Textures | Procedural Textures Support: JT: Partial support | PRC/U3D: No support   JT Notes: JT includes a generic shader/material node system that enables procedural-style texture effects. Full arbitrary procedural texture programs (e.g. GLSL) are not defined. Impact: Procedural texture allow the modeling of surface details through mathematical functions, along with artistic control over various parameters. Typically, they are used for patterns like wood grain or other semi-regular structures. Since they are not using any pixels as source data, procedural textures have, in principle, infinite resolution and are very lightweight to describe. In this example, a procedural texture is used to model the look of a wooden material. Without support for this feature, in this case, the wooden parts won't show any visible details. |
| Normal Mapping | Normal Mapping Support: JT: Full support | PRC/U3D: Partial support   JT Notes: Normal maps are fully supported in the JT material specification with no stated limitations. PRC/U3D Notes: Limited normal mapping support Impact: Normal maps are used to model shading differences that are arising from small geometric details on a surface, such as fabric structures, visible gaps between bricks forming a wall, or rough rock surfaces. In this example, a normal map is used to model a fabric structure. Without support for this feature, the rendered fabric will look smoother than it actually is in the real world, as the fabric structure won't be visible. |
What's the best way to get JT files into my 3D applications, and are there alternatives to using PRC/U3D?
Doing 3D conversion right, especially at scale, can be tricky, as 3D data is in general a rather complex (yet very powerful!) medium. This also applies to JT and PRC/U3D files - the conversion guide above provides a rough first idea about that. Once you know what you would like to do, tools like RapidPipeline can help you perform the necessary steps, and to even automate the process for thousands or even millions of files.
Especially when introducing pipelines and workflows at scale in an enterprise context, it is usually good to rely on dedicated tools and expertise, making sure you do not introduce any steps into your 3D workflow that are detrimental to the final output's quality, or that take your team too much time (and money).
If you're interested to hire dedicated expertise from the best in the field to help your company reach your goals fast and reliably, please do not hestitate to contact DGG. Being the creators of RapidPipeline, and ambassadors for open 3D standards for more than a decade, we have been building some of the world's most advanced 3D pipelines, having processed many millions of 3D assets.
Therefore, our expertise will help you to reach your goals faster, at scale, and with the least possible friction, since we are focused on maximum interoperability.
To get started with 3D data conversion and optimization today, sign up for a free account!
If you have any questions, feel free to chat with our human team.
