The Complete Rhino 3DM to USD Conversion Guide
General Information
This guide is part of the RapidPipeline 3D Formats Knowledge Database.It shows how to convert Rhino 3DM to USD, if you'd like to know more about the formats, please check out the following links:
Converting and Optimizing Rhino 3DM Files to USD
There are various ways to convert between Rhino 3DM and USD. With RapidPipeline, you can easily convert and and optimize Rhino 3DM files, at scale. It supports USD, as well as many other file formats (examples: FBX, glTF, OBJ, PLY, STL, USDZ, VRM), at high quality.
Below you can see how to convert your files:
What are Rhino 3DM and USD files commonly used for?
The Rhino 3DM file is a format mostly used for NURBS-based 3D modeling and design.
The USD file is a format mostly used for 3D modeling and rendering applications, and exchange of 3D authoring data.
Best-in-Class 3D Processing in Your Favorite Tools.
100% Local Processing via Desktop Software.
Comparison of Features Supported by Rhino 3DM and USD
| Feature | Supported by Rhino 3DM | Supported by USD |
|---|---|---|
| Morph Targets | No | Yes |
| Rigid Animations | No | Yes |
| Skinned Animations | No | Yes |
| Animations | No | Yes |
| Free-Form Surfaces | Yes | Yes |
| Geometry Compression | No | No |
| Quad Meshes | Yes | Yes |
| Basic 3D Geometry | Yes | Yes |
| PBR Materials | Yes | Yes |
| Transparent Materials | Yes | Yes |
| Vertex Colors | Yes | Yes |
| Materials | Yes | Yes |
| Scene Composition | Yes | Yes |
| Hierarchical Scene Graph | Yes | Yes |
| Scene Nodes | Yes | Yes |
| Standardized Format | Partial0 | Yes |
| Embedded Textures | Partial1 | No |
| Multiple UV Channels | Yes | Yes |
| Normal Mapping | Yes | Yes |
| Procedural Textures | Partial2 | Yes |
| Texture Compression | No | Partial3 |
| Texture Transforms | Yes | Yes |
| Texturing | Yes | Yes |
Best-in-Class 3D Processing in Your Favorite Tools.
100% Local Processing via Desktop Software.
Limitations of Rhino 3DM Files to USD Conversion Workflow
The following limitations should be taken into account when converting Rhino 3DM files to USD format:
| Rhino 3DM Feature (not supported by USD) | Limitation Details |
|---|---|
| Embedded Textures | Embedded Textures Support: Rhino 3DM: Partial support | USD: No support   Rhino 3DM Notes: Textures can be embedded in the 3DM file Impact: Embedded textures allow the storage and exchange of an entire 3D model and its materials within a single file, by embedding the texture images directly into the 3D file (and not storing them as separate image files). Without support for this feature, textures have to be stored in separate image files, and referenced from the main 3D model file. |
What's the best way to get Rhino 3DM files into my 3D applications, and are there alternatives to using USD?
Doing 3D conversion right, especially at scale, can be tricky, as 3D data is in general a rather complex (yet very powerful!) medium. This also applies to Rhino 3DM and USD files - the conversion guide above provides a rough first idea about that. Once you know what you would like to do, tools like RapidPipeline can help you perform the necessary steps, and to even automate the process for thousands or even millions of files.
Especially when introducing pipelines and workflows at scale in an enterprise context, it is usually good to rely on dedicated tools and expertise, making sure you do not introduce any steps into your 3D workflow that are detrimental to the final output's quality, or that take your team too much time (and money).
If you're interested to hire dedicated expertise from the best in the field to help your company reach your goals fast and reliably, please do not hestitate to contact DGG. Being the creators of RapidPipeline, and ambassadors for open 3D standards for more than a decade, we have been building some of the world's most advanced 3D pipelines, having processed many millions of 3D assets.
Therefore, our expertise will help you to reach your goals faster, at scale, and with the least possible friction, since we are focused on maximum interoperability.
To get started with 3D data conversion and optimization today, sign up for a free account!
If you have any questions, feel free to chat with our human team.
