The Complete Parasolid to COLLADA Conversion Guide.
Table of Contents
- General Information
- Converting and Optimizing Parasolid Files to COLLADA
- What are Parasolid and COLLADA files commonly used for?
- Comparison of Features Supported by Parasolid and COLLADA
- Limitations of Parasolid Files to COLLADA Conversion Workflow
- What's the best way to get Parasolid files into my 3D applications, and are there alternatives to using COLLADA?
General Information
This guide is part of the RapidPipeline 3D Formats Knowledge Database. It shows how to convert Parasolid to COLLADA, if you'd like to know more about the formats, please check out the following links:
Converting and Optimizing Parasolid Files to COLLADA
There are various ways to convert between Parasolid and COLLADA. With RapidPipeline, you can easily convert and and optimize Parasolid files, at scale. It supports COLLADA, as well as many other file formats (examples: FBX, glTF, OBJ, PLY, STL, USD, USDZ, VRM), at high quality.
Below you can find a video explaining how to convert your files:
Comparison of Features Supported by Parasolid and COLLADA
| Feature | Supported by Parasolid | Supported by COLLADA |
|---|---|---|
| Morph Targets | No | Yes |
| Rigid Animations | No | Yes |
| Skinned Animations | No | Yes |
| Animations | No | Yes |
| Free-Form Surfaces | Yes | Partial0 |
| Geometry Compression | No | No |
| Quad Meshes | Yes | Yes |
| Basic 3D Geometry | Yes | Yes |
| PBR Materials | No | Partial1 |
| Transparent Materials | No | Yes |
| Vertex Colors | No | Yes |
| Materials | Partial2 | Yes |
| Scene Composition | Yes | Yes |
| Hierarchical Scene Graph | Yes | Yes |
| Scene Nodes | Yes | Yes |
| Standardized Format | Yes | Yes |
| Embedded Textures | No | No |
| Multiple UV Channels | No | Yes |
| Normal Mapping | No | Yes |
| Procedural Textures | No | Partial3 |
| Texture Compression | No | No |
| Texture Transforms | No | Yes |
| Texturing | No | Yes |
Limitations of Parasolid Files to COLLADA Conversion Workflow
The following limitations should be taken into account when converting Parasolid files to COLLADA format:
| Parasolid Feature (not supported by COLLADA) | Limitation Details |
|---|---|
| Free-Form Surfaces | Free-Form Surfaces Support: Parasolid: Full support | COLLADA: Partial support   COLLADA Notes: Limited NURBS support, primarily polygonal Impact: Free-form surfaces allow a CAD user to design surfaces with advanced controls over curvature and continuitiy. While these surfaces are common for CAD models (in the form of so-called boundary representations or "B-reps"), they need to be converted to polygonal triangle or quad data to work with most 3D rendering engines - a process called tessellation. In this example, a surface patch is used to describe a part of a curved surface of a product. Without support for this feature, the free-form surface has to be tessellated into quads or triangles. |
What's the best way to get Parasolid files into my 3D applications, and are there alternatives to using COLLADA?
Doing 3D conversion right, especially at scale, can be tricky, as 3D data is in general a rather complex (yet very powerful!) medium. This also applies to Parasolid and COLLADA files - the conversion guide above provides a rough first idea about that. Once you know what you would like to do, tools like RapidPipeline can help you perform the necessary steps, and to even automate the process for thousands or even millions of files.
Especially when introducing pipelines and workflows at scale in an enterprise context, it is usually good to rely on dedicated tools and expertise, making sure you do not introduce any steps into your 3D workflow that are detrimental to the final output's quality, or that take your team too much time (and money).
If you're interested to hire dedicated expertise from the best in the field to help your company reach your goals fast and reliably, please do not hestitate to contact DGG. Being the creators of RapidPipeline, and ambassadors for open 3D standards for more than a decade, we have been building some of the world's most advanced 3D pipelines, having processed many millions of 3D assets.
Therefore, our expertise will help you to reach your goals faster, at scale, and with the least possible friction, since we are focused on maximum interoperability.
To get started with 3D data conversion and optimization today, sign up for a free account!
If you have any questions, feel free to chat with our human team.
