The Complete STL to IGES Conversion Guide
Table of Contents
- General Information
- Converting and Optimizing STL Files to IGES
- What are STL and IGES files commonly used for?
- Comparison of Features Supported by STL and IGES
- Limitations of STL Files to IGES Conversion Workflow
- What's the best way to get STL files into my 3D applications, and are there alternatives to using IGES?
General Information
This guide is part of the RapidPipeline 3D Formats Knowledge Database. It shows how to convert STL to IGES, if you'd like to know more about the formats, please check out the following links:
Converting and Optimizing STL Files to IGES
RapidPipeline can import STL files, but currently doesn't support exporting to IGES format yet.
If you specifically need IGES export functionality for your workflow, please feel free to get in touch with us - we'd be happy to discuss your requirements and potential timeline for adding this export capability.
If you need, you can import IGES files and convert them to any of these 8 formats: FBX, glTF, OBJ, PLY, STL, USD, USDZ, and VRM.
In the meantime, you can explore other options on the 3D Formats Knowledge Database, which might serve as suitable alternatives for your workflow depending on your target applications and use cases.
Comparison of Features Supported by STL and IGES
| Feature | Supported by STL | Supported by IGES |
|---|---|---|
| Morph Targets | No | No |
| Rigid Animations | No | No |
| Skinned Animations | No | No |
| Animations | No | No |
| Free-Form Surfaces | No | Yes |
| Geometry Compression | No | No |
| Quad Meshes | No | Yes |
| Basic 3D Geometry | Yes | Yes |
| PBR Materials | No | No |
| Transparent Materials | No | No |
| Vertex Colors | No | Partial0 |
| Materials | No | Partial1 |
| Scene Composition | No | Partial2 |
| Hierarchical Scene Graph | No | Partial3 |
| Scene Nodes | No | Yes |
| Standardized Format | Yes | Partial4 |
| Embedded Textures | No | No |
| Multiple UV Channels | No | No |
| Normal Mapping | No | No |
| Procedural Textures | No | No |
| Texture Compression | No | No |
| Texture Transforms | No | No |
| Texturing | No | No |
Limitations of STL Files to IGES Conversion Workflow
The following limitations should be taken into account when converting STL files to IGES format:
| STL Feature (not supported by IGES) | Limitation Details |
|---|---|
| Standardized Format | Standardized Format Support: STL: Full support | IGES: Partial support   IGES Notes: Legacy format, superseded by STEP in 1994 Impact: Standardization plays a huge role in 3D model formats. With a format being standardized, every application will have a clear way of how to load or store data using this format. This makes it easier to re-use the 3D model across different applications, but also to make sure it will still be accessible and usable after a couple of years. |
What's the best way to get STL files into my 3D applications, and are there alternatives to using IGES?
Doing 3D conversion right, especially at scale, can be tricky, as 3D data is in general a rather complex (yet very powerful!) medium. This also applies to STL and IGES files - the conversion guide above provides a rough first idea about that. Once you know what you would like to do, tools like RapidPipeline can help you perform the necessary steps, and to even automate the process for thousands or even millions of files.
Especially when introducing pipelines and workflows at scale in an enterprise context, it is usually good to rely on dedicated tools and expertise, making sure you do not introduce any steps into your 3D workflow that are detrimental to the final output's quality, or that take your team too much time (and money).
If you're interested to hire dedicated expertise from the best in the field to help your company reach your goals fast and reliably, please do not hestitate to contact DGG. Being the creators of RapidPipeline, and ambassadors for open 3D standards for more than a decade, we have been building some of the world's most advanced 3D pipelines, having processed many millions of 3D assets.
Therefore, our expertise will help you to reach your goals faster, at scale, and with the least possible friction, since we are focused on maximum interoperability.
To get started with 3D data conversion and optimization today, sign up for a free account!
If you have any questions, feel free to chat with our human team.
